Dahua IPC-S2XP-6M0WED 6MP Dual-Lens Pan & Tilt Wi-Fi Security Camera – Professional Product Details

The Dahua IPC-S2XP-6M0WED is a smart 6MP dual-lens Wi-Fi security camera designed to provide wider and more comprehensive indoor surveillance. Featuring two 3MP image sensors, the camera delivers 3MP + 3MP resolution (2304 × 1296) for clear and detailed monitoring.

The camera combines a fixed lens and a pan & tilt lens, allowing users to monitor different areas with greater flexibility. The pan & tilt lens supports 0°–355° horizontal pan and 0°–90° vertical tilt, while the fixed lens provides an additional viewing perspective.

With 15-meter infrared night vision, the camera provides reliable monitoring in low-light and dark environments. Its smart detection system supports motion detection, human detection, pet detection, configurable detection regions, and abnormal sound alarms, helping users receive more relevant security alerts.

The IPC-S2XP-6M0WED also supports two-way audio, allowing convenient communication through its built-in microphone and speaker. With 8× digital zoom, users can digitally enlarge important areas for closer viewing.

For connectivity, the camera supports 2.4GHz Wi-Fi 6, 100Mbps Ethernet, ONVIF, and the Imou App for iOS and Android devices. A MicroSD card slot supports up to 512GB, providing convenient local video storage.

Key Features

• 6MP dual-lens camera with 3MP + 3MP resolution

• Dual-camera design with fixed and pan & tilt lenses

• 2304 × 1296 resolution per lens

• 0°–355° pan and 0°–90° tilt on the PT lens

• 15-meter infrared night vision

• 8× digital zoom

• Human and pet detection

• Motion detection

• Abnormal sound alarm

• Configurable detection region

• Two-way audio with built-in microphone and speaker

• H.265/H.264 video compression

• Up to 15fps frame rate

• 2.4GHz Wi-Fi 6 support

• 100Mbps Ethernet port

• ONVIF support

• MicroSD card support up to 512GB

• Imou App support for iOS and Android

• Compact design with low power consumption

Camera Specifications

Model: IPC-S2XP-6M0WED
Camera Type: Dual-Lens Pan & Tilt Wi-Fi Camera
Image Sensor: 1/2.8-inch 3MP Progressive CMOS × 2
Resolution: 3MP + 3MP, 2304 × 1296
Lens: 3.6mm Fixed Lens
Fixed Lens Viewing Angle: 84° H, 45° V, 101° D
PT Lens Viewing Angle: 84° H, 45° V, 101° D
Fixed Lens Movement: 0°–355° Pan, 0°–15° Tilt
Pan & Tilt Lens Movement: 0°–355° Pan, 0°–90° Tilt
Night Vision: Up to 15m
Digital Zoom: 8×
Video Compression: H.265 / H.264
Frame Rate: Up to 15fps
Audio: Two-way audio
Detection: Motion, Human, Pet
Sound Detection: Abnormal Sound Alarm
Network: 2.4GHz Wi-Fi 6 and 100Mbps Ethernet
Wi-Fi Standard: IEEE 802.11b/g/n/ax
Storage: MicroSD up to 512GB
App: Imou App for iOS and Android
Protocol: ONVIF
Power Supply: DC 5V / 1.5A
Power Consumption: Less than 5.65W
Operating Temperature: -10°C to +45°C
Operating Humidity: Less than 95% RH
Dimensions: 82.2 × 82.2 × 115.4mm
Weight: 225g
Certifications: CE, UKCA

Package Contents

• 1 × IPC-S2XP-6M0WED Camera

• 1 × Quick Start Guide

• 1 × Power Adapter

• 1 × USB Cable

• 1 × Screw Package

• 1 × Quick Installation Board

• 1 × Installation Position Map

Ideal for

The Dahua IPC-S2XP-6M0WED is an excellent choice for home monitoring, offices, shops, apartments, reception areas, baby monitoring, pet monitoring, and other indoor security applications where dual-angle coverage and smart detection are required.
